Configure Health Checks#

Health checks control how the broker decides whether a process is healthy. They are observed by the broker monitor after a process starts and then at the configured interval.

health check demo

Lifecycle#

A newly started service reports health="unknown" until a check passes or the startup period expires. A passing check changes it to healthy. A failing check during start_period_s keeps the service in starting; a failing check after that period changes it to unhealthy.

cb start is not a readiness gate. It returns after the process is started and the first health check may run shortly afterwards. Use cb wait SERVICE when a script needs a ready service, and cb status SERVICE to inspect the current health state.

When a check fails:

  • restart_policy="never" leaves the process state visible as unhealthy and does not restart it.

  • restart_policy="on-failure" or "always" emits service.unhealthy, stops the process with the configured graceful stop behavior, and schedules a restart with exponential backoff.

  • The scheduled restart emits service.restart_scheduled with data.reason == "health".

Process Health#

HealthCheck(type="process")

The process is healthy while the child process is still alive.

TCP Health#

HealthCheck(type="tcp", host="127.0.0.1", port=8765, interval_s=5, timeout_s=1)

Use TCP checks for services with a local socket but no HTTP endpoint.

If the service declares an endpoint, bind the check to that endpoint:

HealthCheck(type="tcp", endpoint="default", interval_s=5, timeout_s=1)

HTTP Health#

HealthCheck(type="http", url="http://127.0.0.1:8765/health")

HTTP status codes from 200 through 399 are healthy. Client and server error responses are unhealthy.

Endpoint-bound HTTP checks use the resolved endpoint URL:

HealthCheck(type="http", endpoint="default", interval_s=5, timeout_s=1)

Exec Health#

import sys

HealthCheck(
    type="exec",
    command=(sys.executable, "-m", "my_provider.healthcheck"),
)

Use exec checks for custom local validation. Keep them fast, deterministic, and side-effect-light.

Exec health checks inherit the service’s merged environment, working directory, and broker-injected endpoint variables. They still run as separate child commands. Prefer absolute commands or provider-controlled module commands, and keep timeouts short. Health check I/O runs outside the supervisor state lock, so status queries remain responsive while a check is in progress.

Startup Period#

The default start_period_s is five seconds. During that period, failing checks do not restart the service. This matters for services that need a moment to bind a dynamically assigned endpoint port.

HealthCheck(type="http", endpoint="default", start_period_s=10)

Set start_period_s=0 when the first failed check should immediately count as an unhealthy service.
